Automotive-Qualified Qspeed Silicon Diodes Feature Lowest Qrr for Efficient, High-Switching-Speed Designs

Power Integrations (Nasdaq: POWI), the leader in high-voltage integrated
circuits for energy-efficient power conversion, today announced its 600 V 12
A Qspeed diode, delivering the industry’s lowest reverse recovery charge
(Qrr) for a silicon diode. With a Qrr of just 14 nC at 25 °C, it improves
efficiency of the PFC stage of on-board chargers and significantly reduces
the thermals of the PFC MOSFETs. The AEC-Q101-qualified QH12TZ600Q offers
the same low-switching loss performance of a silicon carbide (SiC) device
without the disadvantages of moving to more expensive technology.

Edward Ong, senior product marketing manager at Power Integrations said:
“The Qrr of these new Qspeed diodes is half that of the next best ultra-fast
silicon diodes, resulting in very high system efficiency. This is
particularly important for automotive on-board charger applications that
require higher switching frequency to reduce volume and weight, and enables
the Qspeed diodes to replace SiC devices.”

The QH12TZ600Q uses merged PiN and Schottky diode technology to achieve high
performance. Its smooth reverse recovery current transition characteristics
not only increase efficiency, but also reduce EMI and peak reverse voltage
stress, eliminating the need for snubbers when used as output rectifiers in
on-board chargers. Devices are available in the compact, 2.5 kV isolated
TO-220 package which enables direct mounting to metal heat sinking,
facilitating excellent thermal performance.

Availability & Resources
The new 600 V 12 A Qspeed diodes are priced at $1.17 in 10,000-piece
quantities. For further inquiries contact a Power Integrations sales
representative or one of the company’s authorized worldwide distributors:
Digikey, Farnell, Mouser, and RS Components.

About Power Integrations
Power Integrations, Inc. is a leading innovator in semiconductor
technologies for high-voltage power conversion. The company’s products are
key building blocks in the clean-power ecosystem, enabling the generation of
renewable energy as well as the efficient transmission and consumption of
power in applications ranging from milliwatts to megawatts. For more
information, please visit www.power.com.
